| Type of Product | Φ25 TWS Series |
| Model No | ASLS331611DNA-202 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Φ25 TWS Series |
Model No |
ASLS331611DNA-202 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
1A1B |
Protection Class |
IP54 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Standard |
UL standard (file no. E68961), CSA standard (file no. LR21451), EN standard (EN60947-5-1), CCC standard (GB14048.5) |
Storage Temperature |
-40 To 80°C (No Icing) |
Monotaro ID |
48040766 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Both Returns (Left/Right To Center, Automatic Return) |
Mounting Hole Diameter (Φmm) |
25.5 mm (0 - 0.5) |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Insulation Voltage (V) |
600 V |
Type of Illumination |
LED |
Notch Angle |
45° |
Number of Notches |
3 |
Name |
Illuminated Selector Switch |
Lamp Voltage (V) |
AC100/110 V |
