| Type of Product | Flash silhouette LB Series selector switch |
| Model No | LB6S33LT2 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Flash silhouette LB Series selector switch |
Model No |
LB6S33LT2 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2C |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-30-80°C (No Icing) |
Contact Material |
Gold Contacts (Gold On Silver, Crossbar Contacts) |
Monotaro ID |
9512677 |
Terminal Shape |
Soldering Tab Terminal |
Import Country |
Direct Import from Japan |
Shape |
Round Type |
Specifications |
Return Direction: Both Returns (Left/Right → Middle, Automatic Return) |
Operation Ambient Temperature (°C) |
-25 To 60°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
3A |
Rated Insulation Voltage (V) |
250 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Operation Mechanism |
Lever Type |
Operation method |
Spring Return Type |
Mechanical Life (10,000 Times) |
25 or More |
Withstand voltage (V / min) |
Between live parts and ground: AC2000, between different polarity terminals: AC2000, between same polarity terminals: AC1000 |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
5-55 Hz, Single Amplitude 0.5 mm |
Bezel Color |
Black |
