| Type of Product | LB Series compact selector switch |
| Model No | LB3K2ST2C1H |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
LB Series compact selector switch |
Model No |
LB3K2ST2C1H |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2C |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-30-80°C (No Icing) |
Contact Material |
Gold Contacts (Gold On Silver, Crossbar Contacts) |
Monotaro ID |
9512607 |
Key |
Reversible type |
Import Country |
Direct Import from Japan |
Shape |
Rectangular |
Specifications |
Φ16 Selector Switch Short Body Standard Type |
Operation Ambient Temperature (°C) |
-25 To 60°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
3A |
Rated Insulation Voltage (V) |
250 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Notch Angle |
90° |
Operation method |
Each Position Stop Type |
Number of Notches |
2 |
Withstand voltage (V / min) |
Between live parts and ground: AC2000, between different polarity terminals: AC2000, between same polarity terminals: AC1000 |
Key Omission |
Missing right (missing left) |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
5-55 Hz, Single Amplitude 0.5 mm |
