Ships within 25 days
View
View
View
View
| Type of Product | Flash silhouette LW Series |
| Model No | LW6ML-M1C22VG |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Flash silhouette LW Series |
Model No |
LW6ML-M1C22VG |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2C |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Gold On Silver, Crossbar Contacts |
Monotaro ID |
47977608 |
Terminal Shape |
Printed Circuit Board Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
25.3 mm (-0.1 - 0.2) |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
3A |
Rated Insulation Voltage (V) |
250 V |
Operation Mechanism |
Round (Flat Lens) |
Type of Illumination |
LED |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Name |
Illuminated Pushbutton Switch |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
Lamp Voltage (V) |
AC/DC6 V |
