Ships within 25 days
View
View
View
View
| Type of Product | HW Series Emergency Stop Push Button Switch (Screw Terminal Type) |
| Model No | HW1B-X413R-MAU |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
HW Series Emergency Stop Push Button Switch (Screw Terminal Type) |
Model No |
HW1B-X413R-MAU |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
1A3B |
Type |
Finished Product |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Gold Contacts |
Monotaro ID |
48000726 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Push Lock Key Reset |
Mounting Hole Diameter (Φmm) |
22.3 mm (0 - +0.4) |
Button Shape |
Large (Φ40) |
Button Color |
Red |
Operation Ambient Temperature (°C) |
-25 To 60°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Type of Illumination |
Non-illuminated |
Short Circuit Protection Device |
250V/10A fuse |
Vibration Resistance (Malfunction) |
5 To 55 Hz, Single Amplitude 0.5 mm |
Name |
Emergency Stop Pushbutton Switch |
Vibration Resistance (Destruction) |
30 Hz, Single Amplitude 1.5 mm |
