| Type of Product | IP Series pushbutton switch |
| Model No | IPR3SAD2 |
| Vibration Resistance | 10 - 500Hz 10G(IEC 60512-6-4, Test 6d) |
| Shock Resistance | 100G(IEC 60512-6-3, Test 6c) |
Type of Product |
IP Series pushbutton switch |
Model No |
IPR3SAD2 |
Vibration Resistance |
10 - 500Hz 10G(IEC 60512-6-4, Test 6d) |
Shock Resistance |
100G(IEC 60512-6-3, Test 6c) |
Material |
Thermoplastic |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
1No |
Bezel Material |
Zinc die casting |
Contact Resistance |
100 mΩ Max.(Initial Value) |
Storage Temperature |
-40 To 85°C (But No Freezing) |
Contact Material |
Silver, Gold Plated |
Monotaro ID |
48015180 |
Terminal Shape |
Solder Terminal Type |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Button Shape |
Round/Curved Surface |
Button Color |
Black |
Operation Ambient Temperature (°C) |
-40 To 85°C (But No Freezing) |
Type of Illumination |
Non-illuminated |
Withstand voltage (V) |
AC1500 (between terminals), AC1000 (between terminals and frame) |
Stroke (mm) |
2.5±0.3 |
Lens Material |
Polycarbonate |
Insulation Resistance (GΩ) |
1min. (DC500V mega) |
