| Type of Product | TW Series |
| Model No | AVLW412611DR |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
TW Series |
Model No |
AVLW412611DR |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
1A1B |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Monotaro ID |
48028550 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Push Lock Turn Reset |
Mounting Hole Diameter (Φmm) |
22.3 mm (0 - 0.4) |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Insulation Voltage (V) |
600 V |
Type of Illumination |
LED |
Name |
Illuminated Push Button Switch (Led Illuminated) |
Lamp Voltage (V) |
AC115/120 V |
