Ships within 25 days
View
View
View
View
| Type of Product | Φ30 TWND Series zinc die-cast push button switch |
| Model No | ABGW420Y-MAU |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Φ30 TWND Series zinc die-cast push button switch |
Model No |
ABGW420Y-MAU |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2A |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Gold On Silver, Crossbar Contacts |
Monotaro ID |
80735587 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
22.3 mm (0 - 0.4) |
Button Shape |
Round Type (With Large Frigate) |
Button Color |
Yellow |
Operation Ambient Temperature (°C) |
-25 To 70°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Name |
Push Button Switch |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
