| Type of Product | Φ30 TWN Series selector switch |
| Model No | ASN2K20NBNO9 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Φ30 TWN Series selector switch |
Model No |
ASN2K20NBNO9 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2A |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Silver |
Monotaro ID |
9510184 |
Key |
NO.9 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Stop At Each Position (Manual) |
Operation Ambient Temperature (°C) |
-25 To 70°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Operation Mechanism |
Key Operation Type |
Notch Angle |
90° |
Number of Notches |
2 |
Withstand voltage (V / min) |
AC2500 (between live and non-live parts) / AC2000 (pilot light AC/DC 6V, 12V, 24V) |
Key Omission |
Left missing (right missing) |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
