| Type of Product | HW Series selector switch |
| Model No | HW1F33L22N1M2R |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
HW Series selector switch |
Model No |
HW1F33L22N1M2R |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2A-2B |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Silver Contacts |
Monotaro ID |
9511855 |
Import Country |
Direct Import from Japan |
Specifications |
Φ22 Selector Switch Standard Type Return Direction: Both Returns |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Operation Mechanism |
Lever Type |
Notch Angle |
45° |
Operation method |
Spring Return Type |
Number of Notches |
3 |
Withstand voltage (V / min) |
Between live parts and non-live parts: AC2500 (however, AC2000 for direct lighting units) |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
Illuminated Colors |
Red |
Rated Operating Voltage (V) |
AC200 / 220 (lighting part) |
