| Type of Product | Φ12 A2 Series illuminated push button switch (long rectangular type) |
| Model No | AL2H-M21JW |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Φ12 A2 Series illuminated push button switch (long rectangular type) |
Model No |
AL2H-M21JW |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2C |
Protection Class |
IP40 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-30-80°C (No Icing) |
Contact Material |
Silver |
Monotaro ID |
47970145 |
Terminal Shape |
Solder Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
12 mm (0 - 0.2) |
Specifications |
Inner Storage Ball: Lad-Sjwn |
Operation Ambient Temperature (°C) |
-25 To 55°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
3A |
Rated Insulation Voltage (V) |
250 V |
Operation Mechanism |
Rectangular |
Type of Illumination |
LED |
Color of Operating Part |
Pure White |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.75 mm |
Name |
Illuminated Pushbutton Switch |
Vibration Resistance (Destruction) |
5-55 Hz, Single Amplitude 0.75 mm |
Rated Current (mA) |
20 |
