| Type of Product | ARN type monolever switch |
| Model No | ARN4-0222-00110220B |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
ARN type monolever switch |
Model No |
ARN4-0222-00110220B |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
Input Order For Each Operation Direction: Up → Right → Down → Left When The Lever Is Blocked → 1A1B Contact → 2B Contact → 2A Contact |
Type |
Long Lever Type |
Protection Class |
IP65(IEC 60529) |
Contact Material |
Silver |
Monotaro ID |
47983664 |
Import Country |
Direct Import from Japan |
Operation Type |
Operation Lever Entry Sequence For Each Direction: Up → Right → Down → Left Operation Prevention → Automatic Return → Automatic Return → Automatic Return |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Electrical Life (10,000 Times) |
over 50 |
Mechanical Life (10,000 Times) |
Over 50 |
No. of Tiers |
4 (Contact Block) |
Withstand voltage (V / min) |
Between live parts and non-live parts: AC2500 |
Storage Temperature Range |
-35 To 80°C (But Do Not Freeze) |
Color (knob) |
Black |
