| Type of Product | Key operated selector 22MM |
| Model No | HW1K-2JPC21 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Key operated selector 22MM |
Model No |
HW1K-2JPC21 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
2A-1B |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Silver Contacts |
Monotaro ID |
66001942 |
Key |
Standard key number (500) |
Import Country |
Direct Import from Japan |
Specifications |
Pin Tumbler Type Cam Designation Symbol: J Or No Designation |
Operation Ambient Temperature (°C) |
-25 To 60°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Notch Angle |
90° |
Operation method |
Each Position Stop Type |
Number of Notches |
2 |
Mechanical Life (10,000 Times) |
More than 10 |
Withstand voltage (V / min) |
Between live parts and non-live parts: AC2500 |
Key Omission |
Missing right (missing left) |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
