| Type of Product | Foot Switch |
| Model No | SFVA-1 |
| Material | Body/Cover: Aluminum alloy die-cast Return spring: SWP (piano wire) Shaft: SS400 (steel) |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFVA-1 |
Material |
Body/Cover: Aluminum alloy die-cast Return spring: SWP (piano wire) Shaft: SS400 (steel) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Contact Configuration |
1c |
Protection Class |
IP30 |
Withstand Voltage |
AC 1500V/min |
Operating Force |
29.4N |
No. of Port |
1 train |
Switch Type |
V type micro switch |
Monotaro ID |
37651731 |
Rating |
AC 250 V/5 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Specifications |
General-purpose small |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
5 |
Mass (g) |
260 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Paint Color |
Blue Newton R22-706 equivalent |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable Size |
VCTF 3 heart x 0.75mm² x 1 m |
