Ships within 19 days
View
View
View
View
| Type of Product | Foot Switch |
| Model No | SFK-1H |
| Material | (Main body / cover) ABS resin, polycarbonate resin, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Bottom plate) SPCC |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFK-1H |
Material |
(Main body / cover) ABS resin, polycarbonate resin, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Bottom plate) SPCC |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
(Cover) Gray, (Main unit) Black |
Contact Configuration |
1A |
Type |
Mini, compact resin |
Application |
Various office equipment, medical equipment, measuring instruments, consumer equipment, etc. |
Protection Class |
IP30 |
Operating Force |
9.8N |
No. of Port |
1 train |
Switch Type |
S type micro |
Monotaro ID |
2024873 |
Rating |
AC 250 V/3 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
3 |
Withstand voltage (V / min) |
AC 1500 |
Mass (g) |
250 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Alternate |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 2 corex0.75 mm2x1m |
