| Type of Product | Foot Switch |
| Model No | SFKB-2DW |
| Material | (Return spring) SWP, (Shaft) SS400, (Bottom plate) SPCC |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFKB-2DW |
Material |
(Return spring) SWP, (Shaft) SS400, (Bottom plate) SPCC |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Gray |
Contact Configuration |
1st stage 1a, 2nd stage 1a |
Type |
Waterproof type |
Protection Class |
IPx8 equivalent |
Operating Force |
1st stage 15N or more, 2nd stage 30N or more |
No. of Port |
2 stations |
Switch Type |
Waterproof V type micro switch gold grad contact |
Monotaro ID |
2025214 |
Ambient Humidity to Use |
85% RH or less |
Main Unit Material |
ABS resin |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Cover Material |
ABS resin |
Rated Carrying Current (A) |
3 (standard rating/less than 100V AC), 0.001 (micro rating/5V DC, resistive load) |
Cable Length (m) |
MVVS 4 coresx0.5 mm²x1.5m |
Withstand voltage (V) |
AC 1500/min |
Rated Voltage (V) |
Less than AC100 (3A/standard rating), DC5 (0.001A or more/micro rating, resistive load) |
Operating Patterns |
Momentary |
Rated Current (A) |
3A |
Insulation Resistance (MOhm) |
100 mohm or more (DC 500 V) |
