| Type of Product | Foot Switch |
| Model No | SFO-1-2 |
| Material | Body: ABS resin, Return spring: SWP (piano wire), Bottom plate: SPCC (unichrome plated) |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFO-1-2 |
Material |
Body: ABS resin, Return spring: SWP (piano wire), Bottom plate: SPCC (unichrome plated) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Red-green |
Contact Configuration |
1ax2 |
Type |
General-purpose mini type |
Application |
Medical equipment, measuring equipment, OA equipment, precision equipment, amusement, electronic equipment, etc. |
Protection Class |
IP30 |
Withstand Voltage |
AC 1500V/min |
Operating Force |
3.92N |
No. of Port |
2 stations |
Monotaro ID |
37651783 |
Rating |
AC 250 V 5 Amp |
Ambient Humidity to Use |
85% RH or less |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Cover Material |
ABS resin |
Rated Carrying Current (A) |
5 |
Mass (g) |
900 |
Rated Voltage (V) |
AC250 (resistance load) |
Operating Patterns |
Momentary |
Rated Current (A) |
5 (resistive load) |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable Size |
VCTF 4 corex0.75 mm²x1.5 m |
