Ships within 25 days
View
View
View
View
| Type of Product | Foot Switch |
| Model No | SFZ-1 |
| Material | Body: Aluminum alloy die-cast, Return spring: SWP (piano wire), Seal nut: Polyacetal resin |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFZ-1 |
Material |
Body: Aluminum alloy die-cast, Return spring: SWP (piano wire), Seal nut: Polyacetal resin |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Contact Configuration |
1c |
Type |
General-purpose popular type |
Protection Class |
IP30 |
Withstand Voltage |
AC 1500V/min |
Operating Force |
19.6N |
No. of Port |
1 train |
Monotaro ID |
37651747 |
Rating |
AC 250 V 10A |
Ambient Humidity to Use |
85% RH or less |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Cover Material |
Aluminum alloy die casting |
Rated Carrying Current (A) |
10 |
Mass (g) |
450 |
Rated Voltage (V) |
AC250 (resistance load) |
Operating Patterns |
Momentary |
Paint Color |
Metallic R25-635 equivalent |
Rated Current (A) |
10 (resistive load) |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable Size |
VCTF 3 corex1.25 mm²x1 m |
Shaft Material |
SS400 (steel material) |
