| Type of Product | Foot Switch |
| Model No | SF-1H |
| Material | (Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Seal nut) Polyacetal resin |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SF-1H |
Material |
(Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Seal nut) Polyacetal resin |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Metallic R25-635 equivalent |
Contact Configuration |
1A |
Protection Class |
IP30 |
Operating Force |
34.3N |
No. of Port |
1 train |
Switch Type |
Lock type push button |
Monotaro ID |
2024794 |
Rating |
AC 250 V/6 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
6 |
Withstand voltage (V / min) |
AC 1500 |
Mass (g) |
470 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Alternate |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 2 heart x 0.75 mm² x 1m |
