| Type of Product | Foot Switch |
| Model No | SFQ-1 BW |
| Material | (Return spring) SUS, (Bottom plate) SPCC |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFQ-1 BW |
Material |
(Return spring) SUS, (Bottom plate) SPCC |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Black |
Contact Configuration |
1A |
Type |
Waterproof type |
Protection Class |
IPx8 equivalent |
Operating Force |
8.8N |
No. of Port |
1 train |
Switch Type |
Waterproof V type micro switch gold grad contact |
Monotaro ID |
2025196 |
Ambient Humidity to Use |
85% RH or less |
Main Unit Material |
ABS resin |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Cover Material |
ABS resin |
Rated Carrying Current (A) |
0.005(DC6V), 0.002(DC12V) |
Cable Length (m) |
VCTF 2 coresx0.75 mm²x1.5m |
Withstand voltage (V) |
AC 1500/min |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Rated Current (A) |
5A |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
