| Type of Product | Foot Switch |
| Model No | SFD-2D |
| Material | (Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400 |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFD-2D |
Material |
(Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
R39-236 equivalent |
Contact Configuration |
2c |
Type |
Large, aluminum |
Application |
Press machine, machine tool, shearing machine, industrial machine, etc. |
Protection Class |
IP50 |
Operating Force |
(1 stage) 19.6N, (2 stage) 98.0N |
No. of Port |
1 train |
Switch Type |
Z type micro |
Monotaro ID |
2025065 |
Rating |
AC 250 V/6 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
6 |
Withstand voltage (V / min) |
AC 1500 |
Mass (g) |
3400 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 6 coresx0.75 mm²x1m |
