| Type of Product | Foot Switch |
| Model No | SFU-1R |
| Material | Body/Cover: ABS Resin/Ethylene Vinyl Acetate Return Spring: SUS (Stainless Steel) Bottom Plate: SPCC (Steel Plate) |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFU-1R |
Material |
Body/Cover: ABS Resin/Ethylene Vinyl Acetate Return Spring: SUS (Stainless Steel) Bottom Plate: SPCC (Steel Plate) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Red |
Contact Configuration |
1c |
Protection Class |
IP50 |
Withstand Voltage |
AC 1500V/min |
Operating Force |
11.7 |
No. of Port |
1 train |
Switch Type |
V type micro switch |
Monotaro ID |
37651801 |
Rating |
AC 250 V 6A |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Specifications |
Round type |
Operation Ambient Temperature (°C) |
0 to 40 |
Rated Carrying Current (A) |
6 |
Mass (g) |
340 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable Size |
VCTF 3 cores x 0.75 mm² ) x 1.5 m |
