Ships within 25 days
View
View
View
View
| Type of Product | Foot Switch |
| Model No | SF-2 |
| Material | (Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Seal nut) Polyacetal resin |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SF-2 |
Material |
(Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SS400, (Seal nut) Polyacetal resin |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Metallic R25-635 equivalent |
Contact Configuration |
2c |
Protection Class |
IP30 |
Operating Force |
34.3N |
No. of Port |
1 train |
Switch Type |
Z type micro |
Monotaro ID |
2024785 |
Rating |
AC 250 V/6 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
6 |
Withstand voltage (V / min) |
AC 1500 |
Mass (g) |
600 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 6 coresx0.75 mm²x1m |
