| Type of Product | Foot Switch |
| Model No | SFVA-1-2 |
| Material | (Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SPCC |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFVA-1-2 |
Material |
(Main body / cover) Aluminum alloy die-casting, (Return spring) SWP <Piano wire>, (Shaft) SPCC |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Color |
Blue Newton R22-706 equivalent |
Contact Configuration |
1cx2 |
Type |
Compact / Aluminum |
Application |
Various machine tools, consumer equipment, information equipment, measuring equipment, testing equipment, educational equipment, acoustic equipment, etc. |
Protection Class |
IP30 |
Operating Force |
29.4 |
No. of Port |
2 stations |
Switch Type |
V type micro |
Monotaro ID |
2024846 |
Rating |
AC 250 V/5 Amp |
Ambient Humidity to Use |
85% RH or less |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Rated Carrying Current (A) |
5 |
Withstand voltage (V / min) |
AC 1500 |
Mass (g) |
1180 |
Rated Voltage (V) |
AC 250 |
Operating Patterns |
Momentary |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 6 core x 0.75 mm² x 1m |
