| Type of Product | Foot Switch |
| Model No | SFQ-1 B |
| Material | Body: ABS resin, return spring: SUS (stainless steel), bottom plate: SPCC (steel plate) |
| Country of Origin | Japan |
Type of Product |
Foot Switch |
Model No |
SFQ-1 B |
Material |
Body: ABS resin, return spring: SUS (stainless steel), bottom plate: SPCC (steel plate) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Contact Configuration |
1A |
Type |
Compact round type |
Application |
Electronic application equipment, acoustic equipment, educational equipment, medical electronic equipment, OA equipment, measuring equipment, consumer equipment, machine tools, etc. |
Protection Class |
IP20 |
Operating Force |
8.8N |
No. of Port |
1 train |
Monotaro ID |
2024986 |
Rating |
AC 250 V/6 Amp |
Ambient Humidity to Use |
85% RH or less |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-5 to 40 |
Cover Material |
ABS resin |
Rated Carrying Current (A) |
6 |
Mass (g) |
200 |
Rated Voltage (V) |
AC250 (resistance load) |
Operating Patterns |
Momentary |
Rated Current (A) |
6 (resistive load) |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Cable |
VCTF 2 corex0.75 mm2x1.5m |
Cable Size |
VCTF 2 heart x 0.75 mm² x 1.5 m |
Switch Shape |
(Built-in) V type micro switch |
