| Type of Product | Projection Switch |
| Model No | A22PT11O |
| Mechanical Durability | 5 million times |
| Country of Origin | Japan |
Type of Product |
Projection Switch |
Model No |
A22PT11O |
Mechanical Durability |
5 million times |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Contact Configuration |
1a1b |
Type |
Non-illuminated type |
Protection Class |
IP65 oil-proof type |
Monotaro ID |
37830292 |
Electrical Durability |
1 million times |
Terminal Shape |
Screw terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
22.3(+0.4 to 0) |
Button Shape |
Round (projection) |
Button Color |
Color |
Shape |
Projection (metal ring) |
Operation Ambient Temperature (°C) |
-20 to 55 |
Rated Operating Current (A) |
AC-15 class (inductive load): 24V / 10, 48V / 10, 110V / 6, 220V / 4, 440V / 1.5 DC-13 class (inductive load): 24V / 6, 48V / 2, 110V / 0.7, 220V /0.3 DC-12 class (resistive load): 24V / 6, 48V / 3, 110V / 2, 220V / 1 |
Rated Insulation Voltage (V) |
AC/DC 600 |
Operating Force (N) |
Approx. 11 (Contact configuration 1a1b) |
Relative Humidity |
45 to 85% |
Contact Resistance (ohm) |
30 mΩ or less |
Insulation Resistance (MOhm) |
100 mohm or more (500 V) |
Cold Resistance |
-40 to 70℃ |
Temperature Rise |
40K or less |
Heat Resistant Temperature (℃) |
-40 to 70 |
