| Type of Product | Key Switch |
| Model No | S-300-90-EF-1(#300) |
| Vibration Resistance | Kata Amplitude 0.75 mm, 10-55 Hz Contact Opening 1 ms or less |
| Shock Resistance | 294 m/s² or more (Contact Opening 1 ms or less) |
Type of Product |
Key Switch |
Model No |
S-300-90-EF-1(#300) |
Vibration Resistance |
Kata Amplitude 0.75 mm, 10-55 Hz Contact Opening 1 ms or less |
Shock Resistance |
294 m/s² or more (Contact Opening 1 ms or less) |
Material |
Lock / Free-Cutting Brass Bar (C3602BD), Key / Brass Plate (C3713P) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TAKIGEN MFG CO., LTD |
Withstand Voltage |
(50/60 Hz, 1 Minute), 1000 V AC Between Non-Continuous Terminals, 1500 V AC Between Each Terminal and Non-Continuous Metal Part, 1500 V AC Between Each Terminal and Ground |
Contact Resistance |
50 or less (Initial Value) |
Contact Material |
Silver Plating |
Included Components |
2 Keys |
Surface Finish Type |
Lock / Chrome Plating (MBCr) Key / Nickel Plating |
TAKIGEN Code |
40634 |
Monotaro ID |
62818184 |
Ambient Humidity to Use |
85% RH or less (No Condensation) |
Durability |
More than 10 million times Mechanically, more than 50,000 times Electrical |
Insulation Resistance |
100 mΩ or more (500 VDC) |
Operation Ambient Temperature |
-25 to + 85°C (No Freezing) |
Minimum Applicable Load |
DC15 V / 0.1 A (Resistive Load) |
Key |
300 |
Import Country |
Direct Import from Japan |
