| Type of Product | Key Switch |
| Model No | S-388-180-E-2(#W01388) |
| Vibration Resistance | 10-55 Hz, Double Amplitude 1.5 mm |
| Shock Resistance | 15G or more |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Key Switch |
Model No |
S-388-180-E-2(#W01388) |
Vibration Resistance |
10-55 Hz, Double Amplitude 1.5 mm |
Shock Resistance |
15G or more |
Material |
Body: Free-Cutting Brass Bar (C3604BD), Key: Brass Plate (C3713P) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TAKIGEN MFG CO., LTD |
Withstand Voltage |
(50/60 Hz) Non-Continuous Terminal: AC1000 V/Min, Between Each Terminal and Non-Charging Metal Part: AC1500 V/Min |
Contact Material |
Silver Plating |
Included Components |
2 Keys |
Surface Finish Type |
Body: Chrome Plating (MBCr), Key: Nickel Plating (Mbni) |
TAKIGEN Code |
40648 |
Monotaro ID |
53468635 |
Conflict resistance (initial value) |
50 mΩ or less |
Rating |
Resistive Load: AC125 V/3 A, AC250 V/3 A, DC30 V/3 A, DC125 V/0.4 A / Inductive Load: AC125 V/2 A, AC250 V/2 A, DC30 V/2 A, DC125 V/0.05 A |
Ambient Humidity to Use |
85% RH or less (No Condensation) |
Durability |
Mechanical: 500,000 times or more, Electrical: 50,000 times or more |
Insulation Resistance |
100 mΩ or more (500 VDC) |
Operation Ambient Temperature |
-25 to + 85°C (No Freezing) |
Minimum Applicable Load |
DC15 V / 0.1 A (Resistive Load) |
