| Type of Product | Operational Amplifier |
| Output Current | 200 (Sink) μ Amp, 600 (Source) μ Amp |
| Dimension | 9.91x7.87x4.45 mm |
| Length | 9.91 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Operational Amplifier |
Output Current |
200 (Sink) μ Amp, 600 (Source) μ Amp |
Dimension |
9.91x7.87x4.45 mm |
Length |
9.91 mm |
Country of Origin |
UK |
Pack of |
50 Pcs |
Name of Manufacturer/Packer/Importer |
Maxim Integrated |
Package Type |
DIP |
Pin Count |
8 |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
0°C |
Output Type |
Rail to Rail |
Width |
7.87 mm |
Height |
4.45 mm |
Minimum Input Voltage |
2.5 V |
Maximum Input Voltage |
10 V |
Power Supply Type |
Single |
Typical Single Supply Voltage |
2.5 to 10 V |
Number of Channels Per Chip |
1 |
Amplifier Type |
Operational Amplifier |
Manufacturer Part Number |
MAX406BCPA+ |
Maximum Operating Frequency |
1 kHz |
Slew Rate |
20 V/ms |
Product Code |
1913206 |
Typical Gain Bandwidth Product |
40 kHz |
Voltage Gain |
1000 V/ mV |
Typical Input Voltage Noise Density |
150nV/√Hz |
Offset Voltage |
3 mV |
Input Voltage Range |
2.5 to 10 V |
