| Type of Product | Operational Amplifier |
| Dimension | 8.75x4x1.5 mm |
| Length | 8.75 mm |
| Country of Origin | UK |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Operational Amplifier |
Dimension |
8.75x4x1.5 mm |
Length |
8.75 mm |
Country of Origin |
UK |
Pack of |
5 Pcs |
Name of Manufacturer/Packer/Importer |
Maxim Integrated |
Package Type |
SOIC |
Pin Count |
14 |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Output Type |
Rail to Rail |
Width |
4 mm |
Height |
1.5 mm |
Minimum Input Voltage |
2.7 V |
Maximum Input Voltage |
6 V |
Power Supply Type |
Dual, Single |
Typical Single Supply Voltage |
2.7 to 6 V |
Number of Channels Per Chip |
4 |
Typical Dual Supply Voltage |
±11.35 to ±13 V |
Amplifier Type |
Low Voltage |
Manufacturer Part Number |
MAX4094ASD+ |
Slew Rate |
0.20 V/±5s |
Product Code |
1915004 |
Typical Gain Bandwidth Product |
500 kHz |
Voltage Gain |
115 dB |
Typical Input Voltage Noise Density |
12nV/√Hz |
Rail to Rail |
Rail to Rail Input/Output |
Offset Voltage |
±13.5 mV |
Input Voltage Range |
2.7 to 6 V |
Input Offset Current |
20 nA |
