| Country of Origin | China |
| Width | 150 mm |
| Product Type | Fixed Installation DC-AC Power Inverter |
| Type of Product | Fixed Installation DC-AC Power Inverter |
Country of Origin |
China |
Width |
150 mm |
Product Type |
Fixed Installation DC-AC Power Inverter |
Type of Product |
Fixed Installation DC-AC Power Inverter |
Weight |
1.73 Kg |
Input Voltage |
24 V DC |
Length |
284 mm |
Efficiency (%) |
92% |
Output Voltage |
230 V AC |
Output Power |
700 W |
Depth |
81 mm |
Output Current |
3.04 Amp |
MTBF |
86852kH |
Protection Features |
Over Temperature Protection 60 ±5°C, P Voltage, Reverse Polarity Protection Yes, Re-Power on to Recover, Over Voltage Protection 30 to 32V, 140 ±9°F, Overload Protection >840W Shut Down O, Short Circuit Protection Shut Off |
Minimum Operating Temperature |
-20°C |
Maximum Operating Temperature |
50°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Mount Type |
Chassis |
Output connector |
Universal Socket |
No. Of Output |
1 |
Standards/Approvals |
CE, RoHS, UKCA |
