Ships within 25 days
View
View
View
View
| Model No | RSLP-12K-2RC |
| Material | AES Resin & PBT+PC Resin |
| Type of Product | Louver |
| Color | Cream |
Model No |
RSLP-12K-2RC |
Material |
AES Resin & PBT+PC Resin |
Type of Product |
Louver |
Color |
Cream |
Country of Origin |
Japan |
Protection Class |
IP3X |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Included Components |
Plug cord (2m), mounting screws, instruction manual |
Pack of |
1 Piece |
Specifications |
With filter (polyester, dust removal rate 80%) |
Import Country |
Direct Import from Japan |
Monotaro ID |
16639017 |
Rated Voltage (V) |
AC100 (single phase) |
RoHS Directive |
Correspondence |
Dimensions C (mm) |
10 |
Dimensions B (mm) |
120 |
Dimensions D (mm) |
48 |
Dimensions A (mm) |
120 |
Installation Location |
For indoor use |
Rated Power Consumption (W) |
10/8.3 |
Noise Level Db(A) |
About 38/43 |
Input terminals |
2 terminals |
Rated Frequency (Hz) |
50/60 |
Maximum Airflow (m³/min) |
0.36/0.45 |
Operating Temperature (c) |
-10 to 60 |
Maximum Static Pressure (Pa) |
38/51 |
Mounting Ventilation Fan |
PF-091C-2 |
