| Type | G type |
| Series | OPCP Series |
| Features | Waterproof And Dustproof |
| Model No | OPCP303018G |
Type |
G type |
Series |
OPCP Series |
Features |
Waterproof And Dustproof |
Model No |
OPCP303018G |
Material |
[Top Cover] Polycarbonate (Ul94V-2), [Body And Extension] Glass Fiber Reinforced Polycarbonate (Ul94V-0), [Gasket] Polyurethane, [Cover Screw] Polyamide, [Mounting Base Screw (Tapping Screw)] Iron |
Type of Product |
Polycarbonate Box |
Color |
[Top Cover, Body, Extension, Cover Screw] White Gray, [Gasket] Black |
Country of Origin |
Japan |
Protection Class |
IP65 |
Body Material |
Glass Fiber Reinforced Polycarbonate (Ul94V-0) |
Operating Temperature Range |
-20 to +75℃ |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
2.19 |
Body Color |
White gray |
Cover Color |
Top: White Grey |
Import Country |
Direct Import from Japan |
Monotaro ID |
88224543 |
Surface Treatment |
Mounting Base Screws (Tapping Screws): Nickel Plated |
Tightening Torque (Nm) |
1 to 2 |
Material (Gasket) |
Polyurethane |
Outer Dimension d (mm) |
300 |
Outer Dimension W (mm) |
300 |
Outer Dimension H (mm) |
187 |
Cover Material |
Flame-Retardant Abs Resin (Ul94V-0 Main Component) |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Effective dimension (width) (mm) |
280.9 (Internal) |
Effective dimension (depth) (mm) |
225.1 (Internal) |
