Ships within 19 days
View
View
View
View
| Series | MOR Series |
| Model No | MOR177-43-35BS |
| Type of Product | Aluminum Rack Case |
| Color | Silver (Panel)/Black (Top And Bottom Covers)/Black (Side Frame) |
Series |
MOR Series |
Model No |
MOR177-43-35BS |
Type of Product |
Aluminum Rack Case |
Color |
Silver (Panel)/Black (Top And Bottom Covers)/Black (Side Frame) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
4.3 |
Specifications |
●Material (front panel): Aluminum plate A1100P t2.0 ●Material (rear panel): Aluminum plate A1100P t2.0 ●Material (side frame): Aluminum extrusion material A6063S-T5 ●Material (front frame): Aluminum extrusion material A6063S- T5●Material (rear frame): Aluminum extrusion material A6063S-T5●Material (upper cover): Aluminum plate A1100P t1.0●Material (corner block): Aluminum die-cast ADC12●Material (rear feet): Flame-retardant ABS (UL94V) -0 main components) ●Material (rack mount bracket): Aluminum extrusion material A6063S-T5 ●Material (lower cover): Aluminum plate A1100P t1.0 ●Surface treatment (front panel): Silver anodized/black anodized ●Surface treatment (rear panel) ): Silver anodized, black anodized ●Surface treatment (side frame): Gray painted, black painted ●Surface treatment (front frame): Gray painted, black painted ●Surface treatment (rear frame): Silver anodized ●Surface treatment (top cover): Painting ●Surface treatment (corner block): Gray painting, black painting ●Surface treatment (rack mount bracket): Gray painting, black painting ●Surface treatment (lower cover): Painting ●Color (rear feet): Grain gray, Grain black ●Color (Top cover): Light gray/black ●Color (lower cover): Light gray/black ●Quantity: Front panel, rear panel, upper cover, lower coverx1, side frame, front frame, rear frame, corner block, rear feet x2, rubber feet x4 |
Screw Type |
Yes (Flat M4x6 Trivalent Chromatex4, Pan M4x8 Trivalent Chromatex8, Bind M4x10 Trivalent Black Chromatex4, Flat Head M5x10 Trivalent Black Chromatex4, Fixing Nut For M5x4 ) |
Import Country |
Direct Import from Japan |
Monotaro ID |
88344243 |
Dimension D (Φmm) |
350 |
Dimension W |
430 mm |
Dimension H (Φmm) |
177 |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Material (Rubber Feet) |
Polyurethane |
Rubber Foot |
Black |
