| Type | T type |
| Series | DPCP Series |
| Features | Waterproof And Dustproof |
| Model No | DPCP152008T |
Type |
T type |
Series |
DPCP Series |
Features |
Waterproof And Dustproof |
Model No |
DPCP152008T |
Material |
[Top Cover, Body] Polycarbonate (Ul94V-2), [Gasket] Polyurethane, [Cover Screw (Tapping Screw)] Stainless Steel, [Blind Plug] Polycarbonate, [Mounting Base Screw (Tapping Screw)] Iron |
Type of Product |
Polycarbonate Box |
Color |
[Top Cover] Transparent, [Body, Blind Plug] White Gray, [Gasket] Black |
Country of Origin |
Japan |
Protection Class |
IP66/67 |
Operating Temperature Range |
-20 to +75℃ |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
418 |
Body Color |
White gray |
Cover Color |
Top: Transparent |
Import Country |
Direct Import from Japan |
Monotaro ID |
88222574 |
Surface Treatment |
[Cover Screw (Tapping Screw)] Untreated, [Mounting Base Screw (Tapping Screw)] Nickel Plated |
Outer Dimension d (mm) |
200 |
Outer Dimension W (mm) |
150 |
Outer Dimension H (mm) |
76 |
Color (Munsell value) |
[Body] Ral 7035 Approximation Color |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Effective dimension (width) (mm) |
139.5 (Internal) |
Effective dimension (depth) (mm) |
171.5 (Internal) |
Effective Dimension (height) (mm) |
56.7 (Internal) |
