| Series | HIT Series |
| Model No | HIT13-3-13BB |
| Type of Product | Small Heat Dissipation Case |
| Color | Black |
Series |
HIT Series |
Model No |
HIT13-3-13BB |
Type of Product |
Small Heat Dissipation Case |
Color |
Black |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
289 |
Specifications |
●Material (upper and lower panels): Aluminum plate A1100P ●Material (front and rear panels): Aluminum plate A1100P ●Material (heat sink side plates): Aluminum extrusion material A6063S-T5 ●Surface treatment (heat sink side plates): Silver anodized/black anodized ●Surface treatment ( Front and rear panels): Silver anodized, hairline black anodized -Surface treatment (upper and lower covers): Silver anodized, hairline black alumite -Surface treatment (screws): Hexagonal hole plate M3x8: Trivalent black chromate |
Thermal Resistance |
6.82 ℃ / W |
Import Country |
Direct Import from Japan |
Monotaro ID |
88335405 |
Dimension D (Φmm) |
119.8 |
Dimension C (Φmm) |
118.6 |
Dimension W |
130 mm |
Dimension B (Φmm) |
122 |
Dimension A (Φmm) |
8 |
Screw Material |
Flat Plate With Hexagonal Hole M3x8: Iron |
Dimension H (Φmm) |
30 |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Material (Rubber Feet) |
Polyurethane |
Dimension E (Φmm) |
26 |
Rubber Foot |
Black |
