| Type | With Opening |
| Series | CSS Series |
| Model No | CSS75N-OP-WB |
| Material | Battery terminal: Stainless steel SUS304, Silicon cover: Silicon rubber, Mounting Screws (pan head tapping M1.6x6): Iron |
Type |
With Opening |
Series |
CSS Series |
Model No |
CSS75N-OP-WB |
Material |
Battery terminal: Stainless steel SUS304, Silicon cover: Silicon rubber, Mounting Screws (pan head tapping M1.6x6): Iron |
Type of Product |
Plastic Case with Silicone Cover |
Color |
White & Black |
Country of Origin |
Japan |
Operating Temperature Range |
-10 to 60℃ |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
24 |
Import Country |
Direct Import from Japan |
Monotaro ID |
88366573 |
Surface Treatment |
Battery terminal: Nickel plated, Mounting Screws (pan head tapping M1.6x6): Nickel plated, trivalent black chromate |
Material (Gasket) |
Top/Bottom/Battery: ABS resin (UL94HB) |
Outer Dimension d (mm) |
78.6 (Plastic case dimensions: 75) |
Outer Dimension W (mm) |
38.6 (Plastic case dimensions: 35) |
Outer Dimension H (mm) |
15.5 (Plastic case dimensions: 12) |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Treatment |
Top/bottom/battery: Grain (Cover) |
Effective Internal Dimensions / width (mm) |
26.6(w) |
Effective Internal Dimensions / height (mm) |
5.3(h) |
Effective Internal Dimensions / depth (mm) |
59(d) |
Battery Type |
None |
