| Series | WH Series |
| Features | Waterproof / Flame Retardant |
| Model No | WH145-33-M2-BB |
| Material | Battery Cover: Flame-Retardant Abs Resin (Ul94V-0 Main Component), Side Grip: Elastomer, Anti-Drop Screw (Pan Head M2.5x8) / Mounting Screw (Pan Head M2.5x10): Stainless Steel Sus304, Battery Terminal: Brass |
Series |
WH Series |
Features |
Waterproof / Flame Retardant |
Model No |
WH145-33-M2-BB |
Material |
Battery Cover: Flame-Retardant Abs Resin (Ul94V-0 Main Component), Side Grip: Elastomer, Anti-Drop Screw (Pan Head M2.5x8) / Mounting Screw (Pan Head M2.5x10): Stainless Steel Sus304, Battery Terminal: Brass |
Type of Product |
Waterproof Handheld Case |
Color |
Black / Black |
Country of Origin |
Japan |
Protection Class |
IP67 |
Operating Temperature Range |
-10 to 60℃ |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
180.5 |
Import Country |
Direct Import from Japan |
Monotaro ID |
17969762 |
Surface Treatment |
Battery Cover: Textured, Battery Terminals: Nickel Plated, Cover: Top/Bottom: Grain |
Tightening Torque (Nm) |
Cover: 0.2 to 0.3 |
Material (Gasket) |
Silicon Rubber |
Outer Dimension d (mm) |
146 |
Outer Dimension W (mm) |
88 |
Outer Dimension H (mm) |
33 |
Cover Material |
Top/Bottom: Flame-Retardant Abs Resin (Ul94V-0 Main Component) |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Effective dimension (width) (mm) |
69.2 (Internal) |
Effective dimension (depth) (mm) |
51.5 (Internal) |
Effective Dimension (height) (mm) |
21 (Inside) |
Structure |
AAx2 |
Material (O-ring) |
Silicon Rubber |
