Ships within 19 days
View
View
View
View
| Series | WGV Series |
| Model No | WGV23-25-11W |
| Material | Asa Resin (Ul94Hb) |
| Type of Product | Box with Ip68 Internal Pressure Adjustment Vent |
Series |
WGV Series |
Model No |
WGV23-25-11W |
Material |
Asa Resin (Ul94Hb) |
Type of Product |
Box with Ip68 Internal Pressure Adjustment Vent |
Color |
Gasket: Black, Internal Pressure Adjustment Vent Plug: Light Gray |
Country of Origin |
Japan |
Protection Class |
IP68 |
Body Material |
Asa Resin (Ul94Hb) |
Operating Temperature Range |
-30 to 60℃ |
Name of Manufacturer/Packer/Importer |
Takachi Electric Industrial Co., Ltd. |
Weight (g) |
646.5 |
Body Color |
Off white |
Cover Color |
Off white |
Import Country |
Direct Import from Japan |
Monotaro ID |
70397725 |
Tightening Torque (Nm) |
Cover: 0.5 to 0.6, Vent Plug: 0.6 to 0.8 |
Material (Gasket) |
Silicon Rubber |
Outer Dimensions |
225x245x110 mm |
Cover Material |
Asa Resin (Ul94Hb) |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Mounting Screw |
M4x10 |
Inner Dimensions, Width W x Depth D x Height H (mm) |
177x191x97.5 (Effective Dimensions) |
