| Type of Product | LCD Colour Display |
| Backlight | LED |
| Country of Origin | China |
| Brightness | 220 cd/m² |
Type of Product |
LCD Colour Display |
Backlight |
LED |
Country of Origin |
China |
Brightness |
220 cd/m² |
Response Time |
30 ms |
Contrast Ratio |
400:1 |
Operating Temperature Range |
-20-+70°C |
Display Mode |
Transmissive |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-20°C |
Resolution |
320x240pixels |
Supply Voltage |
20.4 V |
Height |
66 mm |
Aspect Ratio |
0.16875000000000001 |
Interface Type |
8-Bit, 9-Bit, 16-Bit, 18-Bit, SPI |
Width |
87 mm |
Name of Manufacturer/Packer/Importer |
Displaytech |
Display Size (Inch) |
3.5 inch |
Manufacturer Part Number |
INT035TFT-TS |
No. of Colors |
16777216 |
Product Code |
7502572 |
Screen Type |
Resistive |
Display Matrix Technology |
TFT |
Touch Screen Controller |
Yes |
Viewing Area Dimensions |
70.08x52.56 mm |
Diagonal Display Size |
88.90 mm |
Graphics Array Type |
QVGA |
Power Supply Included |
Yes |
