| Type of Product | Passive Matrix OLED Display |
| Country of Origin | US |
| Dimension | 34.40x48.80x1.41 mm |
| Display Color | White |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Passive Matrix OLED Display |
Country of Origin |
US |
Dimension |
34.40x48.80x1.41 mm |
Display Color |
White |
Contrast Ratio |
10000:1 |
Operating Temperature Range |
-40 to +80°C |
Maximum Operating Temperature |
+80°C |
Minimum Operating Temperature |
-40°C |
Resolution |
160x128 Pixels |
Height |
1.41 mm |
Aspect Ratio |
48.8:1.41 |
Depth |
1.41 mm |
Width |
34.4 mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Manufacturer Part Number |
MDOT160128CV-WM |
Forward voltage (V) |
3.5 V DC |
Screen Size |
4.87 cm (1.92 inch) |
Viewing Area Height |
28.908 mm |
Viewing Area Width |
39.34 mm |
Viewing Area Dimensions |
28.908x39.34 mm |
Driver Mounting |
COT |
Interface Port(s) |
I2C, Parallel, SPI |
Matrix Type |
Passive |
