| Type of Product | Alphanumeric LCD Display |
| Backlight | LED |
| Country of Origin | Taiwan, Province Of China |
| Display Type | Alphanumeric |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Alphanumeric LCD Display |
Backlight |
LED |
Country of Origin |
Taiwan, Province Of China |
Display Type |
Alphanumeric |
Character Height |
4.7 mm |
External Dimension |
74.3x36.4x9 mm |
Operating Temperature Range |
-20 to +70°C |
Display Mode |
Transmissive |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-20°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Manufacturer Part Number |
MCCOG42005A6W-BNMLWI |
Viewing Area Height |
22.18 mm |
Viewing Area Width |
60.5 mm |
Display Matrix Technology |
STN |
Viewing Area Dimensions |
61x22 mm |
External Depth |
9 mm |
External Height |
36.4 mm |
Background Color |
Blue |
Character Matrix |
4 Rows x 20 Characters |
Character Rows |
4 |
Character Width |
2.5 mm |
Characters Per Row |
20 |
Driver Mounting |
COG |
