| Rated Power | 96 W |
| Efficiency (%) | 0.92 |
| Application | Skyscraper Lighting, Street Lighting, Floodlight Lighting, Stage Lighting, Horticulture Lighting, Bay Lighting, DMX Power Supply, Household Devices, Retail and Refrigerated Display |
| Series | XLG |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Power |
96 W |
Efficiency (%) |
0.92 |
Application |
Skyscraper Lighting, Street Lighting, Floodlight Lighting, Stage Lighting, Horticulture Lighting, Bay Lighting, DMX Power Supply, Household Devices, Retail and Refrigerated Display |
Series |
XLG |
Type of Product |
Constant Power Mode LED Driver |
Total Harmonic Distortion |
THD< 10%(@load≧50%/115 VAC, 230VAC; @load≧75%/277 VAC) |
Model No |
XLG-100I-12A |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
ITMS Powertech Private Limited |
Ripple & Noise (max) |
150 mVp-p |
Storage Humidity |
10 ~ 95% RH |
Voltage (Dc) |
12 V |
Protection |
Over Current, Short Circuit, Over Voltage, Over Temperature |
Frequency Range |
47-63 Hz |
Current Adjust Range |
4-8 A |
Rated Current |
8 A |
Hold Up Time |
10 ms/ 230 VAC, 10 ms/ 115 VAC |
Working Humidity |
20 ~ 95% RH non-condensing |
Load Regulation |
±2% |
Constant Current Region |
8.4-12 V |
Leakage Current |
<0.75 mA / 277 VAC |
Line Regulation |
±0.5% |
Storage Temperature |
-40 to +80°C |
Voltage Tolerance |
±3% |
