| Protection Class | IP54 |
| Type of Product | LED Stack Light |
| Color | Red-green |
| Model No | VT10K-200E2W |
Protection Class |
IP54 |
Type of Product |
LED Stack Light |
Color |
Red-green |
Model No |
VT10K-200E2W |
Body Material |
ASA |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Nichiei Manufacturing Co., Ltd. |
Cable Type |
Input line: AWG#22 800 mm, Power line: AWG#18 800 mm |
Number of Blinks (Times / Minute) |
60 |
Lens Material |
PC |
Power Consumption (W) |
6 |
Import Country |
Direct Import from Japan |
Function |
Wide Power, Flashing, Speaker, WAV, Volume |
Monotaro ID |
20934456 |
Outer Diameter (Φmm) |
100 |
Mass (Kg) |
1.14 |
Height H (mm) |
329 |
Number of LED (pieces) |
8 / stage |
Structure |
Direct mount, LED, outdoor |
No. of Tiers |
2 |
Sound Pressure Level (dB) |
60 to 85 |
Temperature Range (℃) |
-20 to 60 |
Rated Voltage (V) |
AC100 to 200 |
Vibration Resistance |
4.5G |
Contact Capacity |
30 V 30 mA or more |
