| Type of Product | Safety Light Curtain |
| Model No | F3SJ-B1745N25 |
| Protection Class | Ip65(Iec60529) |
| Output | NPN output |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-B1745N25 |
Protection Class |
Ip65(Iec60529) |
Output |
NPN output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety related functions) Interlock (in basic system), external relay monitor (in basic system), muting (in muting system), override (in muting system) |
Response Time |
When stable light is received: (ON→OFF) 15 ms or less (response time for single unit, 2-unit, 3-unit connection)<br> (OFF→ON) 70 ms or less (response time for single unit, 2-link, 3-link) |
Case Material |
Aluminum |
Cell Spacing (mm) |
(Optical Axis) 20 |
Control Output |
Npn Transistor Output X 2, Load Current 200 mA Or Less, Residual Voltage 2 V Or Less (Excluding The Effect Of Cord Extension), Leakage Current 1 mA Or Less, Inductive Load 2.2H Or Less, Allowable Capacitance Load 1Μf |
Monotaro ID |
46472054 |
Power Supply Voltage |
SELV / PELV DC 24 V ± 20% (ripple p-p10% or less) |
Sensor Type |
Type4 Safety Light Curtain |
Import Country |
Direct Import from Japan |
Included Components |
Quick Installation Manual (QIM), instruction manual |
Cap Material |
ABS resin, PBT |
Applicable Standard |
IEC61496-1, EN61496-1, UL61496-1 (Type 4 ESPE), IEC61496-2, EN 61496-2, UL61496-2 (Type 4 AOPD), IEC61508-1~-3, EN61508-1~-3(SIL3), ISO13849-1:2015, EN ISO13849-1:2015(PLe/Safety Category 4), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 |
Power Cable (m) |
0.3 (Cord drawer type with connector) |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (g) |
2936.9 (single unit), 5211.5 (packaged) |
Input Voltage (V) |
Test input, interlock selection input, reset input, muting input: ON voltage: 0 to 3 (short-circuit current approx. 4.0 mA) OFF voltage: 1/2 Vs to Vs or open (short-circuit current approx. 3.0 mA), External relay monitor input: ON voltage: 0 to 3 (short circuit current approx. 5.5 mA) OFF voltage: open |
Lens Diameter (Φmm) |
5 |
Connector |
Setting tool connection → Function setting: Not possible |
Remark |
Confirm Delivery Date Each Time |
