| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A2105N20 |
| Protection Class | Ip65(Iec60529) |
| Output | NPN output |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A2105N20 |
Protection Class |
Ip65(Iec60529) |
Output |
NPN output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (must be set using the setting tool when using the muting function), external relay monitor, muting (lamp disconnection detection, built-in override function. Requires muting key cap type F39-CN6), fixed blanking (must be set using the setting tool), floating blanking (must be set using the setting tool) |
Light Source |
Infrared Led |
Case Material |
Aluminum, zinc die-cast (including metal parts on both ends) |
Cell Spacing (mm) |
(Optical axis) 15 |
Control Output |
Npn Transistor Output X 2, Load Current 300 mA Or Less, Residual Voltage 2 V Or Less (Excluding The Effect Of Cord Extension), Allowable Capacity Load 2.2Μf, Leakage Current 2 mA Or Less (It May Be Different From (On / Off)) |
Monotaro ID |
46470794 |
Power Supply Voltage |
DC 24 V ± 20% (Ripple P-P10% Or Less) |
Sensor Type |
Type4 Safety Light Curtain |
Series |
F3SJ-A20 series |
Import Country |
Direct Import from Japan |
Included Components |
Test Rod, Instruction Manual, Mounting Bracket (Top / Bottom Mounting F39-Lj1), Intermediate Mounting Bracket, Error Mode Label, User'S Manual (Cd-Rom) |
Set Contents |
Emitter, Receiver |
Cap Material |
ABS Resin |
Applicable Standard |
IEC61496-1, EN61496-1, UL61496-1 (Type 4 ESPE), IEC61496-2, EN 61496-2, UL61496-2 (Type 4 AOPD), IEC61508-1~-3, EN61508-1~-3(SIL3), ISO13849-1:2015, EN ISO13849-1:2015(PLe/Safety Category 4), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 |
Sensor |
Type4 Safety Light Curtain |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Input Voltage (V) |
Test input, interlock selection input, reset input, muting input: ON voltage: 0 to 1.5 (short circuit current approx. 1.5 mA) OFF voltage: 9 to Vs, or open External relay monitor input ON voltage: 0 to 1.5 (short circuit current approx. 4.0 mA) OFF voltage: open Note: Vs here is the voltage value in the operating environment. |
Lens Diameter (Φmm) |
5 |
Specifications |
For safety measures of safety category 4, 3, 2, 1, B |
Remark |
Confirm Delivery Date Each Time |
