| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A0785P20-TS |
| Type | Auto Reset Fixed Model |
| Protection Class | Ip65(Iec60529) |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A0785P20-TS |
Type |
Auto Reset Fixed Model |
Protection Class |
Ip65(Iec60529) |
Output |
PNP Output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (must be set using the setting tool when using the muting function), external relay monitor, muting (lamp disconnection detection, built-in override function. Requires muting key cap type F39-CN6), fixed blanking (must be set using the setting tool), floating blanking (must be set using the setting tool) |
Case Material |
Aluminum, zinc die-cast (including metal parts on both ends) |
Cell Spacing (mm) |
(Optical axis) 15 |
Monotaro ID |
46468791 |
Power Supply Voltage |
DC 24 ± 20% (ripple p-p ≤ 10%) |
Sensor Type |
Type4 Safety Light Curtain |
Series |
F3SJ-A20 series |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting bracket (for top and bottom mounting, model F39-LJ1), intermediate mounting bracket (*), error mode label, quick installation manual (QIM), * One set of intermediate mounting brackets is included with each transmitter and receiver. |
Set Contents |
Emitter, Receiver |
Applicable Standard |
IEC61496-1, EN61496-1, UL61496-1 (Type 4 ESPE), IEC61496-2, EN 61496-2, UL61496-2 (Type 4 AOPD), IEC61508-1~-3, EN61508-1~-3(SIL3), ISO13849-1:2015, EN ISO13849-1:2015(PLe/Safety Category 4), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 |
Sensor |
Type4 Safety Light Curtain |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Detection Distance (m) |
0.2-9 |
Mass (g) |
1394.5 (single unit), 2677.5 (packaged) |
Input Voltage (V) |
Test input, interlock selection input, reset input, muting input: ON voltage: 9 to Vs (short-circuit current approx. 2.0 mA) OFF voltage: 0 to 1.5, or open External relay monitor input ON voltage: 9 to Vs (short-circuit current approx. 3.5 mA) OFF voltage: open Note: Vs here is the voltage value in the operating environment. |
Lens Diameter (Φmm) |
5 |
Connector |
Setting tool connection → Possible |
Specifications |
Output for external indicator light (non-safety output): Connectable indicator light/incandescent lamp: DC 24 V, 3-7 W, ・LED lamp: Load current 10 to 300 mA, leakage current 1 mA or less (To use the external indicator output, the general-purpose indicator cord Model F39-JJ3N or the dedicated external indicator kit Model F39-A01P□-PAC is required.) |
Remark |
Confirm Delivery Date Each Time |
