| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A1955P20-S-VER2 |
| Type | S-mark compatible model |
| Protection Class | Ip65(Iec60529) |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A1955P20-S-VER2 |
Type |
S-mark compatible model |
Protection Class |
Ip65(Iec60529) |
Output |
PNP Output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (must be set using the setting tool when using the muting function), external relay monitor, muting (lamp disconnection detection, built-in override function. Requires muting key cap type F39-CN6), fixed blanking (must be set using the setting tool), floating blanking (must be set using the setting tool) |
Light Source |
Infrared Led |
Case Material |
Aluminum, zinc die-cast (including metal parts on both ends) |
Cell Spacing (mm) |
(Optical axis) 15 |
Control Output |
Pnp Transistor Output X 2, Load Current 300Ma Or Less, Residual Voltage 2V Or Less (Excluding The Effect Of Cord Extension), Allowable Capacity Load 2.2Μf, Leakage Current 1Ma Or Less (It May Be Different From (On / Off)) |
Monotaro ID |
46470672 |
Power Supply Voltage |
DC 24 V ± 20% (Ripple P-P10% Or Less) |
Sensor Type |
Type4 Safety Light Curtain |
Series |
F3SJ-A20 series |
Import Country |
Direct Import from Japan |
Included Components |
Test Rod, Instruction Manual, Mounting Bracket (Top / Bottom Mounting F39-Lj1), Intermediate Mounting Bracket, Error Mode Label, User'S Manual (Cd-Rom) |
Set Contents |
Emitter, Receiver |
Applicable Standard |
IEC61496-1, EN61496-1, UL61496-1 (Type 4 ESPE), IEC61496-2, EN 61496-2, UL61496-2 (Type 4 AOPD), IEC61508-1~-3, EN61508-1~-3(SIL3), ISO13849-1:2015, EN ISO13849-1:2015(PLe/Safety Category 4), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 |
Sensor |
Type4 Safety Light Curtain |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Input Voltage (V) |
Test input, interlock selection input, reset input, muting input: ON voltage: 9 to Vs (short-circuit current approx. 2.0 mA) OFF voltage: 0 to 1.5, or open External relay monitor input ON voltage: 9 to Vs (short-circuit current approx. 3.5 mA) OFF voltage: open Note: Vs here is the voltage value in the operating environment. |
Lens Diameter (Φmm) |
5 |
Specifications |
S-mark compatible model |
Remark |
Confirm Delivery Date Each Time |
