| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A1395P30-S-VER2 |
| Type | S-mark compatible model |
| Protection Class | Ip65(Iec60529) |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A1395P30-S-VER2 |
Type |
S-mark compatible model |
Protection Class |
Ip65(Iec60529) |
Output |
PNP Output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (must be set using the setting tool when using the muting function), external relay monitor, muting (lamp disconnection detection, built-in override function. Requires muting key cap type F39-CN6), fixed blanking (must be set using the setting tool), floating blanking (must be set using the setting tool) |
Case Material |
Aluminum, zinc die-cast (including metal parts on both ends) |
Cell Spacing (mm) |
(Optical axis) 25 |
Control Output |
Pnp Transistor Output X 2, Load Current 300Ma Or Less, Residual Voltage 2V Or Less (Excluding The Effect Of Cord Extension), Allowable Capacity Load 2.2Μf, Leakage Current 1Ma Or Less (It May Be Different From (On / Off)) |
Monotaro ID |
46470042 |
Power Supply Voltage |
DC 24 V ± 20% (Ripple P-P10% Or Less) |
Sensor Type |
Type4 Safety Light Curtain |
Series |
F3SJ-A30 series |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting bracket (F39-LJ1 for top and bottom mounting), intermediate mounting bracket (*), error mode label, quick installation manual (QIM), * Two sets of intermediate mounting brackets are included with each transmitter and receiver. |
Set Contents |
Emitter, Receiver |
Applicable Standard |
IEC61496-1, EN61496-1, UL61496-1 (Type 4 ESPE), IEC61496-2, EN 61496-2, UL61496-2 (Type 4 AOPD), IEC61508-1~-3, EN61508-1~-3(SIL3), ISO13849-1:2015, EN ISO13849-1:2015(PLe/Safety Category 4), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (g) |
2186.95 (single unit), 4092.5 (packaged) |
Input Voltage (V) |
Test input, interlock selection input, reset input, muting input: ON voltage: 9 to Vs (short-circuit current approx. 2.0 mA) OFF voltage: 0 to 1.5, or open External relay monitor input ON voltage: 9 to Vs (short-circuit current approx. 3.5 mA) OFF voltage: open Note: Vs here is the voltage value in the operating environment. |
Lens Diameter (Φmm) |
5 |
Connector |
Setting tool connection → Possible |
Specifications |
Output for external indicator light (non-safety output): Connectable indicator light/incandescent lamp: DC 24 V, 3-7 W, ・LED lamp: Load current 10 to 300 mA, leakage current 1 mA or less (To use the external indicator output, the general-purpose indicator cord Model F39-JJ3N or the dedicated external indicator kit Model F39-A01P□-PAC is required.) |
Remark |
Confirm Delivery Date Each Time |
