| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A1100N25 |
| Protection Class | Ip65(Iec60529) |
| Output | NPN output |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A1100N25 |
Protection Class |
Ip65(Iec60529) |
Output |
NPN output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (must be set using the configuration tool when using the muting function), external relay monitor, muting (lamp burnout detection, built-in override function. Keycap for muting) F39-CN6 is required), fixed blanking (requires setting with the setting tool), floating blanking (requires setting with the setting tool) |
Light Source |
Infrared Led |
Case Material |
Case (Including Metal Parts At Both Ends): Aluminum, Zinc Die-Cast |
Cell Spacing (mm) |
(Optical Axis) 20 |
Control Output |
Npn Transistor Output X 2, Load Current 300 mA Or Less, Residual Voltage 2 V Or Less (Excluding The Effect Of Cord Extension), Allowable Capacity Load 2.2Μf, Leakage Current 2 mA Or Less (It May Be Different From (On / Off)) |
Monotaro ID |
46469482 |
Power Supply Voltage |
DC 24 V ± 20% (Ripple P-P10% Or Less) |
Import Country |
Direct Import from Japan |
Included Components |
Test Rod, Instruction Manual, Mounting Bracket (Top / Bottom Mounting F39-Lj1), Intermediate Mounting Bracket, Error Mode Label, User'S Manual (Cd-Rom) |
Set Contents |
Emitter, Receiver |
Cap Material |
ABS Resin |
Applicable Standard |
Iec61496-1, En61496-1, Ul61496-1 (Type 4 Espe) Iec61496-2, Clc/Ts61496-2, Ul61496-2 (Type 4 Aopd) Iec61508-1 To -3, En61508-1 To -3 (Sil3) Iec13849-1:2006, En Iso13849-1:2008 (Category 4 Ple) Ul508, Ul1998, Can/Csa C22.2 No.14, Can/Csa C22.2 No.0.8 |
Sensor |
Type4 Safety Light Curtain |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Input Voltage (V) |
Test input: ON voltage: 0V to 3V (short circuit current approx. 4.0mA) OFF voltage: 1 / 2Vs to Vs or open (short circuit current approx. 3.0mA) |
Lens Diameter (Φmm) |
5 |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
Specifications |
Auto Reset Fixed Model |
Remark |
Confirm Delivery Date Each Time |
Cord |
Oil resistant PVC |
